Safety Hitch Pin

Safety Hitch Pin

Lockease™ Safety hitch pin, 1" diameter, 6" usable length.

  • Heavy duty hinged handle and lock.
  • Large collar prevents pin damage.
  • Heavy powder coat prevents corrosion.
  • Patented locking mechanism on top of pin operates with one hand and keeps in securely in drawbar.
  • Heavy duty heat treated pin for superior strength.

Price: $24.50

Shop Now
Crop Divider Hinge

Crop Divider Hinge

Folding crop divider hinge for grain platforms. 2 hinges with hardware.

  • For John Deere platforms
    • 620F, 625F, 630F, 635F
    • 630FD, 635FD, 640FD
    • 730FD, 735FD, 740FD, 745FD

Allows divider to pivot horizontally in front of reel by removing a pin.
Reduces transport width by 3-1/2 ft.
Install by drilling and bolting or welding in place.
Patent No 8726623.

Price: $399.00

Shop Now
Grain Grabber

Grain Grabber

The Grain Grabber 2 improves the feed of your auger making it more like a full fingered auger. Crops feed more evenly with reduced slugging. Mount one between each auger flight with four self-tapping bolts. Requires 17/64 in. drill bit, DB1764, to install. Drill bit sold separately.

Quantity per platform:
18 ft. and less, 4 used.
20 ft., 6 used.
25 ft., 8 used.
30 ft., 10 used.

For AGCO Gleaner Series 3, 300, 400, 500, 700, 800, 7000, 8000, 8200.
Case-IH 1010, 1020, 2010, 2020.
John Deere 200, 900.
Massey Ferguson 7000, 8000, 8200, 9800, 9850.
New Holland 970, 971, 972, 973, 71C, 72C, 73C, 74C.

Price: $29.00

Shop Now
CopperheadAg Concave Set

CopperheadAg Concave Set

CopperheadAg concave set. Includes front, middle, rear concaves and 3 cover plates.

  • For Case-IH combines 1680, 1688, 2188, 2377, 2388, 2577, 2588, 5088, 5130, 5140, 6088, 6130, 6140, 7088, 7130, 7140.

Crop Flexiblity. Harvest all crops with one set of concaves. The Copperhead concave system uses 3 cover plates, 2 in the first concave and 1 in the second. Cover plates are completely adjustable and/or removable which allows you to harvest any crop with the same set of concaves. Easy adjustment makes is it possible to dial in close to zero rotor loss.

Faster Threshing. Machined, 90˚, hard-surfaced, notch on the face of the bars, restricts the flow. Restricted flow forces the grain to thresh quickly, keeping the machine from overloading the separating section. This system does not require the concave to be full to get the grain to thresh properly, restricted flow is what gets the crop to thresh properly.

Less Crop Loss. Copperhead concaves are designed with a 68% larger bar opening than original equipment. The extra space between bars allows threshed grain to unload in the concave section rather than carrying it through to the separating section. By not overloading the seperator the main reason for rotor loss is eliminated.

Price: $5,250.00

Shop Now
